Can be used in underground installations since the cable is very suitable for mechanical compulsion and harsh operating conditions. Suitable for comparatively high ambient temperature due to high maximum permissible conductor temparature.
| Nominal Cross Section mm² | Overall Diameter mm | Net Weight kg/km | Conductor DC Resistance at (20°C) max. ohm/km | Current Carrying Capacity in Ground (A) | Current Carrying Capacity in Air (A) |
|---|---|---|---|---|---|
| 2x25 | 25.0 | 1270 | 1.200 | 111 | 100 |
| 3x25 | 25.6 | 1325 | 1.200 | 111 | 100 |
| 3x35 | 28.2 | 1592 | 0.868 | 132 | 122 |
| 3x50 | 34.6 | 2381 | 0.641 | 157 | 147 |
| 3x70 | 36.5 | 2679 | 0.443 | 195 | 180 |
| 3x95 | 41.8 | 3640 | 0.320 | 233 | 232 |
| 3x120 | 49.0 | 4736 | 0.253 | 266 | 270 |
| 3x25/16 | 27.8 | 1487 | 1.20/1.91 | 111 | 100 |
| 3x35/16 | 30.4 | 1722 | 0.868/1.91 | 132 | 122 |
| 3x50/25 | 35.8 | 2440 | 0.641/1.20 | 157 | 147 |
| 3x70/35 | 39.8 | 2950 | 0.443/0.868 | 195 | 180 |
| 3x95/50 | 45.9 | 4033 | 0.320/0.641 | 233 | 232 |
| 4x25 | 29.1 | 1643 | 1.200 | 111 | 100 |
| 4x35 | 32.2 | 1970 | 0.868 | 132 | 122 |
| 4x50 | 37.7 | 2754 | 0.641 | 157 | 147 |
| 4x70 | 43.0 | 3696 | 0.443 | 195 | 180 |
| 4x95 | 48.2 | 4546 | 0.320 | 233 | 232 |
| 4x120 | 52.2 | 5264 | 0.253 | 266 | 270 |
| 4x150 | 57.7 | 6289 | 0.206 | 299 | 308 |
| 4x185 | 65.6 | 7882 | 0.164 | 340 | 357 |
| 4x240 | 68.4 | 8927 | 0.125 | 401 | 435 |
| 5x16 | 26.1 | 1373 | 1.910 | - | - |
| 5x25 | 30.3 | 1802 | 1.200 | 111 | 100 |
| 5x35 | 34.5 | 2415 | 0.868 | 132 | 122 |
| 5x50 | 39.9 | 3330 | 0.641 | 157 | 147 |
| 5x70 | 45.1 | 4124 | 0.443 | 195 | 180 |
| 5x95 | 50.9 | 5198 | 0.320 | 233 | 232 |
