Installation in walls, on boards and in channels or embedded in plaster.
| Nominal Cross Section mm² | Overall Diameter mm | Net Weight kg/km | Conductor DC Resistance at (20°C) max. ohm/km | Current Carrying Capacity in Air (A) |
|---|---|---|---|---|
| 4 | 6.3 | 69 | 4.95 | 42 |
| 6 | 6.8 | 90 | 3.30 | 54 |
| 10 | 8.3 | 140 | 1.91 | 75 |
| 16 | 9.5 | 201 | 1.21 | 100 |
| 25 | 11.2 | 292 | 0.780 | 133 |
| 35 | 12.3 | 338 | 0.554 | 164 |
| 50 | 14.0 | 531 | 0.386 | 198 |
| 70 | 16.0 | 721 | 0.272 | 253 |
| 95 | 18.0 | 959 | 0.206 | 306 |
| 120 | 19.8 | 1199 | 0.161 | 354 |
| 150 | 22.2 | 1494 | 0.129 | 393 |
| 185 | 25.4 | 1838 | 0.106 | 449 |
| 240 | 28.0 | 2350 | 0.0801 | 528 |
| 300 | 30.6 | 2918 | 0.0641 | 603 |
| 400 | 38.0 | 3951 | 0.0486 | 683 |
