Installation in surface mounted or embedded conduits or similar closed systems. Low level of smoke emission and corrosive gases in case of fire.
| Nominal Cross Section mm² | Overall Diameter mm | Net Weight kg/km | Conductor DC Resistance at (20°C) max. ohm/km | Current Carrying Capacity in Conduit (A) | Current Carrying Capacity in Air (A) |
|---|---|---|---|---|---|
| 1.5 | 2.7 | 21 | 12.1 | 14.5 | 24 |
| 2.5 | 3.3 | 34 | 7.41 | 19.5 | 32 |
| 4 | 3.7 | 50 | 4.61 | 26 | 42 |
| 6 | 4.2 | 71 | 3.08 | 34 | 54 |
| 10 | 5.4 | 116 | 1.83 | 46 | 73 |
| 16 | 7.0 | 161 | 1.15 | 61 | 98 |
| 25 | 8.5 | 258 | 0.727 | 80 | 129 |
| 35 | 9.5 | 346 | 0.524 | 99 | 158 |
| 50 | 11.0 | 468 | 0.387 | 119 | 198 |
| 70 | 12.5 | 660 | 0.268 | 151 | 245 |
| 95 | 15.0 | 910 | 0.193 | 182 | 292 |
| 120 | 16.5 | 1140 | 0.153 | 210 | 344 |
| 150 | 18.0 | 1405 | 0.124 | 240 | 391 |
| 185 | 20.0 | 1745 | 0.0991 | 273 | 448 |
| 240 | 23.0 | 2295 | 0.0754 | 320 | 528 |
| 300 | 26.0 | 2900 | 0.0601 | - | 645 |
| 400 | 29.0 | 3700 | 0.0470 | - | 770 |
