Installation in surface mounted or embedded conduits or similar closed systems at low temperatures.
| Nominal Cross Section mm² | Overall Diameter mm | Net Weight kg/km | Conductor DC Resistance at (20°C) max. ohm/km | Current Carrying Capacity in Conduit (A) | Current Carrying Capacity in Air (A) |
|---|---|---|---|---|---|
| 0.5 | 2.1 | 9 | 39.0 | - | - |
| 0.75 | 2.3 | 12 | 26.0 | - | 16 |
| 1 | 2.5 | 14 | 19.5 | 12 | 20 |
| 1.5 | 3.0 | 20 | 13.3 | 15 | 24 |
| 2.5 | 3.7 | 33 | 7.98 | 20 | 32 |
| 4 | 4.5 | 50 | 4.95 | 25 | 42 |
| 6 | 5.5 | 70 | 3.30 | 33 | 54 |
| 10 | 6.5 | 120 | 1.91 | 45 | 73 |
| 16 | 7.5 | 180 | 1.21 | 61 | 98 |
| 25 | 10.0 | 270 | 0.780 | 83 | 129 |
| 35 | 11.0 | 360 | 0.554 | 103 | 158 |
| 50 | 13.0 | 510 | 0.386 | 132 | 198 |
| 70 | 15.0 | 700 | 0.272 | 165 | 245 |
| 95 | 17.0 | 950 | 0.206 | 197 | 292 |
| 120 | 19.0 | 1150 | 0.161 | 235 | 344 |
| 150 | 21.0 | 1450 | 0.124 | - | 391 |
| 185 | 23.0 | 1750 | 0.106 | - | 448 |
| 240 | 27.0 | 2300 | 0.0801 | - | 528 |
