Used as surface wiring where there is little mechanical damage risk, or in conduit.
| Nominal Cross Section mm² | Overall Diameter mm (Lower Limit / Upper Limit) | Net Weight kg/km | Conductor DC Resistance at (20°C) max. ohm/km (Core / Earth) | Current Carrying Capacity in Air (A) |
|---|---|---|---|---|
| 1x1re | 3.9x5.0 / 4.8x6 | 41 | 18.1/18.1 | 13 |
| 1x1.5+1re | 4.4x5.4 / 5.3x6.6 | 48 | 12.1/18.1 | 16 |
| 1x1.5+1rm | 4.5x5.5 / 5.4x6.7 | 49 | 12.1/18.1 | 16 |
| 2x1+1re | 3.9x7.2 / 4.8x8.7 | 67 | 18.1/18.1 | 13 |
| 2x1.5+1re | 4.4x8.1 / 5.3x9.7 | 83 | 12.1/18.1 | 16 |
| 2x1.5+1rm | 4.5x8.3 / 5.4x10.0 | 84 | 12.1/18.1 | 16 |
| 2x2.5+1.5re | 5.1x9.6 / 6.2x11.7 | 120 | 7.41/12.1 | 21 |
| 2x2.5+1.5rm | 5.2x9.8 / 6.3x11.9 | 121 | 7.41/12.1 | 21 |
| 2x4+1.5rm | 5.7x10.8 / 6.9x13.1 | 172 | 4.61/12.1 | 27 |
| 2x6+2.5rm | 6.4x12.4 / 7.8x15.0 | 235 | 3.08/7.41 | 34 |
| 2x10+4rm | 7.9x15.6 / 9.5x18.9 | 373 | 1.83/4.61 | 45 |
| 2x16+6rm | 8.9x18.1 / 10.8x21.9 | 529 | 1.15/3.08 | 57 |
| 3x1+1re | 3.9x9.4 / 4.8x11.4 | 91 | 18.1/18.1 | 13 |
| 3x1.5+1re | 4.4x10.7 / 5.3x12.9 | 117 | 12.1/18.1 | 16 |
| 3x2.5+1.5re | 5.1x12.6 / 6.2x15.3 | 172 | 7.41/12.1 | 21 |
| 3x4+1.5rm | 5.9x14.8 / 7.1x17.9 | 243 | 4.61/12.1 | 27 |
| 3x6+2.5rm | 6.4x16.8 / 7.8x20.2 | 315 | 3.08/7.41 | 34 |
| 3x10+4rm | 7.9x21.3 / 9.5x25.7 | 516 | 1.83/4.61 | 45 |
| 3x16+6rm | 8.9x24.6 / 10.8x29.7 | 735 | 1.15/3.08 | 57 |
