Installation in walls, on boards and in channels or embedded in plaster.
| Nominal Cross Section mm² | Overall Diameter mm | Net Weight kg/km | Conductor DC Resistance at (20°C) max. ohm/km | Current Carrying Capacity in Conduit (A) |
|---|---|---|---|---|
| 1* re | 3.9 | 26 | 18.1 | 13.5 |
| 1.5* re | 4.2 | 33 | 12.1 | 17.5 |
| 2.5* re | 4.9 | 49 | 7.41 | 24 |
| 4* rm | 6.5 | 69 | 4.61 | 32 |
| 6* rm | 7.5 | 89 | 3.08 | 41 |
| 10* rm | 9.1 | 139 | 1.83 | 57 |
| 16* | 11 | 207 | 1.15 | 76 |
| 25* | 13.5 | 312 | 0.727 | 101 |
| 35* | 13.8 | 410 | 0.524 | 125 |
| 50 | 15.6 | 557 | 0.387 | 151 |
| 70 | 18.2 | 810 | 0.272 | 192 |
| 95 | 20.1 | 1060 | 0.193 | 232 |
| 120 | 21.8 | 1381 | 0.153 | 269 |
| 150 | 21.8 | 1599 | 0.124 | 300 |
| 185 | 23.8 | 1977 | 0.0991 | 341 |
| 240 | 27.2 | 2608 | 0.0754 | 400 |
| 300 | 32.5 | 3055 | 0.0601 | 458 |
