Installation in walls, on boards and in channels or embedded in plaster.
| Nominal Cross Section mm² | Overall Diameter mm | Net Weight kg/km | Conductor DC Resistance at (20°C) max. ohm/km | Current Carrying Capacity in Conduit (A) |
|---|---|---|---|---|
| 1.5 | 4.4 | 31 | 12.1 | 23 |
| 2.5 | 4.8 | 42 | 7.41 | 31 |
| 4 | 5.7 | 63 | 4.61 | 42 |
| 6 | 6.2 | 83 | 3.08 | 54 |
| 10 | 7.3 | 125 | 1.83 | 75 |
| 16 | 8.5 | 183 | 1.15 | 100 |
| 25 | 9.7 | 276 | 0.727 | 133 |
| 35 | 10.9 | 374 | 0.524 | 164 |
| 50 | 13.2 | 522 | 0.387 | 198 |
| 70 | 14.7 | 722 | 0.268 | 253 |
| 95 | 17.2 | 997 | 0.193 | 306 |
| 120 | 19.1 | 1244 | 0.153 | 354 |
| 150 | 20.8 | 1515 | 0.124 | 393 |
| 185 | 23.0 | 1890 | 0.0991 | 449 |
| 240 | 26 | 2441 | 0.0754 | 528 |
| 300 | 28.8 | 3124 | 0.0601 | 603 |
