Used in refineries, hotels, schools, tunnels, high constructions, hospitals, power plats, data processing centers, populated business centers where there is a risk of fire.
| Nominal Cross Section mm² | Overall Diameter mm | Net Weight kg/km | Conductor DC Resistance at (20°C) max. ohm/km | Current Carrying Capacity in Air (A) |
|---|---|---|---|---|
| 2x1.5 | 8.3 | 101 | 12.1 | 22 |
| 2x2.5 | 9.1 | 130 | 7.41 | 30 |
| 2x4 | 10.4 | 182 | 4.61 | 40 |
| 2x6 | 11.4 | 235 | 3.08 | 51 |
| 2x10 | 14.2 | 379 | 1.83 | 70 |
| 2x16 | 16.8 | 548 | 1.15 | 98 |
| 3x1.5 | 8.7 | 118 | 12.1 | 22 |
| 3x2.5 | 9.6 | 157 | 7.41 | 30 |
| 3x4 | 11.0 | 224 | 4.61 | 40 |
| 3x6 | 12.4 | 303 | 3.08 | 51 |
| 3x10 | 15.0 | 475 | 1.83 | 70 |
| 3x16 | 18.2 | 711 | 1.15 | 98 |
| 4x1.5 | 9.3 | 140 | 12.1 | 18.5 |
| 4x2.5 | 10.3 | 189 | 7.41 | 25 |
| 4x4 | 12.3 | 286 | 4.61 | 34 |
| 4x6 | 13.9 | 389 | 3.08 | 43 |
| 4x10 | 16.2 | 589 | 1.83 | 60 |
| 4x16 | 19.8 | 888 | 1.15 | 80 |
| 4x25 | 24.0 | 1359 | 0.727 | 127 |
| 4x35 | 26.7 | 1794 | 0.524 | 158 |
| 5x1.5 | 10.0 | 165 | 12.1 | 18.5 |
| 5x2.5 | 11.1 | 224 | 7.41 | 25 |
| 5x4 | 13.6 | 353 | 4.61 | 34 |
| 5x6 | 15.0 | 467 | 3.08 | 43 |
| 5x10 | 17.6 | 714 | 1.83 | 60 |
| 5x16 | 21.9 | 1098 | 1.15 | 80 |
| 5x25 | 26.1 | 1652 | 0.727 | 127 |
| 7x1.5 | 10.7 | 201 | 12.1 | 15.5 |
| 7x2.5 | 12.3 | 289 | 7.41 | 21 |
