Installation in dry premises, switchboards, and distribution boards, in surface mounted or embedded conduits.
| Type / Nominal Cross Section mm² | Overall Diameter mm | Net Weight kg/km | Conductor DC Resistance at (20°C) max. ohm/km | Current Carrying Capacity in Conduit (A) | Current Carrying Capacity in Air (A) |
|---|---|---|---|---|---|
| H05V-U / 1x0.50 | 2.0 | 9 | 36 | - | - |
| H05V-U / 1x0.75 | 2.2 | 12 | 24.5 | - | 16 |
| H05V-U / 1x1.0 | 2.4 | 13 | 18.1 | 11 | 19 |
| H07V-U / 1x1.5 | 2.7 | 21 | 12.1 | 14.5 | 24 |
| H07V-U / 1x2.5 | 3.2 | 34 | 7.41 | 19.5 | 32 |
| H07V-U / 1x4 | 3.7 | 50 | 4.61 | 26 | 42 |
| H07V-U / 1x6 | 4.2 | 71 | 3.08 | 34 | 54 |
| H07V-U / 1x10 | 5.4 | 116 | 1.83 | 46 | 73 |
