Low voltage household appliances under less mechanical compulsion in high temperature environments.
| Nominal Cross Section mm² | Overall Diameter mm | Net Weight kg/km | Conductor DC Resistance at (20°C) max. ohm/km | Current Carrying Capacity in Air (A) |
|---|---|---|---|---|
| 2x0.50 | 5.0 | 37 | 39.0 | 3 |
| 2x0.75 | 5.5 | 46 | 26.0 | 6 |
| 3x0.50 | 5.0 | 43 | 39.0 | 3 |
| 3x0.75 | 5.5 | 54 | 26.0 | 6 |
| 4x0.50 | 6.0 | 54 | 39.0 | 3 |
| 4x0.75 | 6.5 | 70 | 26.0 | 6 |
| 2x1 | 6.6 | 65 | 19.5 | 10 |
| 2x1.5 | 7.2 | 87 | 13.3 | 16 |
| 2x2.5 | 8.7 | 131 | 7.98 | 25 |
| 3x0.75 | 6.7 | 68 | 26.0 | 6 |
| 3x1 | 6.7 | 77 | 19.5 | 10 |
| 3x1.5 | 8.1 | 106 | 13.3 | 16 |
| 3x2.5 | 9.8 | 164 | 7.98 | 25 |
| 3x4 | 11.4 | 232 | 4.95 | 32 |
| 4x0.75 | 7.1 | 83 | 26.0 | 6 |
| 4x1 | 8.3 | 100 | 19.5 | 10 |
| 4x1.5 | 9.1 | 142 | 13.3 | 16 |
| 4x2.5 | 10.1 | 201 | 7.98 | 25 |
| 5x0.75 | 8.1 | 102 | 26.0 | 6 |
| 5x1 | 8.8 | 124 | 19.5 | 10 |
| 5x1.5 | 10.2 | 175 | 13.3 | 16 |
| 5x2.5 | 12.4 | 254 | 7.98 | 25 |
| 5x4 | 13.9 | 355 | 4.95 | 32 |
