It is used outdoors, indoors, underground and in cable ducts where there are no severe mechanical stresses.
| Nominal Cross Section mm² | Overall Diameter mm | Net Weight kg/km | Conductor DC Resistance Max. ohm/km(20°C) | Current Carrying Capacity (In Earth) | Current Carrying Capacity (In Air) | ||
|---|---|---|---|---|---|---|---|
| Flat | Trefoil | Flat | Trefoil | ||||
| 1x1,5 | 6,15 | 54 | 12,1 | - | 23 | - | - |
| 1x2,5 | 6,54 | 66 | 7,41 | 34 | 31 | - | - |
| 1x4 | 7,01 | 84 | 4,61 | 66 | 54 | 56 | 40 |
| 1x6 | 7,51 | 106 | 3,08 | 82 | 67 | 79 | 53 |
| 1x10 | 8,85 | 157 | 1,83 | 109 | 89 | 101 | 74 |
| 1x16 | 9,80 | 218 | 1,15 | 139 | 115 | 137 | 101 |
| 1x25 | 11,40 | 320 | 0,727 | 179 | 148 | 182 | 135 |
| 1x35 | 12,50 | 418 | 0,524 | 213 | 177 | 226 | 169 |
| 1x50 | 14,20 | 555 | 0,387 | 251 | 209 | 275 | 207 |
| 1x70 | 15,90 | 764 | 0,268 | 307 | 256 | 353 | 268 |
| 1x95 | 17,80 | 1019 | 0,193 | 366 | 307 | 430 | 328 |
| 1x120 | 19,70 | 1269 | 0,153 | 416 | 349 | 500 | 383 |
| 1x150 | 21,40 | 1548 | 0,124 | 465 | 393 | 577 | 444 |
| 1x185 | 23,40 | 1907 | 0,0991 | 526 | 445 | 661 | 510 |
| 1x240 | 26,60 | 2471 | 0,0754 | 610 | 517 | 781 | 607 |
| 1x300 | 28,80 | 3124 | 0,0601 | 927 | 663 | 901 | 697 |
| 1x400 | 34,0 | 3939 | 0,0470 | 1064 | 749 | 1060 | 811 |
| 1x500 | 39,9 | 5073 | 0,0366 | 1127 | 843 | 1252 | 940 |
| 3x1,5 | 11,90 | 194 | 12,1 | 30 | 23 | ||
| 3x2,5 | 12,90 | 242 | 7,41 | 40 | 32 | ||
| 3x4 | 13,80 | 305 | 4,61 | 50 | 42 | ||
| 3x6 | 14,90 | 382 | 3,08 | 65 | 54 | ||
| 3x10 | 17,40 | 557 | 1,83 | 90 | 75 | ||
| 3x16 | 19,60 | 774 | 1,15 | 120 | 100 | ||
| 3x25 | 22,90 | 1130 | 0,727 | 150 | 127 | ||
| 3x35 | 25,40 | 1478 | 0,524 | 175 | 157 | ||
| 4x1,5 | 12,80 | 229 | 12,1 | 30 | 23 | ||
| 4x2,5 | 13,70 | 282 | 7,41 | 40 | 32 | ||
| 4x4 | 14,80 | 365 | 4,61 | 50 | 42 | ||
| 4x6 | 16,00 | 462 | 3,08 | 65 | 54 | ||
| 4x10 | 18,80 | 683 | 1,83 | 90 | 75 | ||
| 4x16 | 21,30 | 962 | 1,15 | 120 | 100 | ||
| 4x25 | 25,00 | 1417 | 0,727 | 150 | 127 | ||
| 4x35 | 27,70 | 1859 | 0,524 | 175 | 157 | ||
| 5x1,5 | 13,50 | 259 | 12,1 | 30 | 23 | ||
| 5x2,5 | 14,60 | 327 | 7,41 | 40 | 32 | ||
| 5x4 | 15,80 | 428 | 4,61 | 50 | 42 | ||
| 5x6 | 17,10 | 545 | 3,08 | 65 | 54 | ||
| 5x10 | 20,0 | 808 | 1,83 | 90 | 75 | ||
| 5x16 | 23,00 | 1160 | 1,15 | 120 | 100 | ||
| 5x25 | 27,20 | 1728 | 0,727 | 150 | 127 | ||
| 5x35 | 30,30 | 2282 | 0,524 | 175 | 157 | ||
