Used as network, lighting and power cable, indoors, outdoors, underground and in cable ducts where there is no mechanical stress.
| Nominal Cross Section mm² | Overall Diameter mm approximately | Net Weight kg/km approximately | Conductor DC Resistance at (20°C) max. ohm/km | Current Carrying Capacity in Air (A) |
|---|---|---|---|---|
| 2x1.5 | 8.5 | 118 | 12.1 | 18 |
| 2x2.5 | 9.7 | 161 | 7.41 | 26 |
| 2x4 | 11.0 | 217 | 4.61 | 34 |
| 3x1.5 | 8.7 | 129 | 12.1 | 18 |
| 3x2.5 | 10.3 | 192 | 7.41 | 26 |
| 3x4 | 12.1 | 274 | 4.61 | 34 |
| 3x6 | 13.2 | 353 | 3.08 | 44 |
| 4x1.5 | 10.0 | 172 | 12.1 | 18 |
| 4x2.5 | 11.4 | 240 | 7.41 | 26 |
| 4x4 | 13.4 | 345 | 4.61 | 34 |
| 4x6 | 14.6 | 446 | 3.08 | 44 |
| 4x10 | 16.5 | 634 | 1.83 | 62 |
| 4x16 | 19.5 | 939 | 1.15 | 82 |
| 5x1.5 | 10.3 | 190 | 12.1 | 18 |
| 5x2.5 | 12.3 | 283 | 7.41 | 26 |
| 5x4 | 14.3 | 405 | 4.61 | 34 |
| 5x6 | 16.0 | 541 | 3.08 | 44 |
| 5x10 | 18.3 | 784 | 1.83 | 63 |
| 5x16 | 21.2 | 1140 | 1.15 | 82 |
| 7x1.5 | 11.6 | 246 | 12.1 | 18 |
| 7x2.5 | 13.3 | 349 | 7.41 | 26 |
